Description
Working Frequency : 860MHz~960MHz
Reading Distance : Up to 10 meters for UHF1-10E and
UHF1-10F (Determined by the environment and reader)
Protocol Standard : ISO/IEC 18000-6C, EPC global
Class 1 Gen 2
Chip : Alien H3
Working Mode : Passive (no battery)
Storage Structure : EPC: 96bits, UID/TID: 64bits, User: 512bits
Kill Password: 32bits, Access Password: 32bits
Erase Endurance : 100,000 Times
Data Storage Period : 10 Years
Working Temperature : 0~60℃
Storage Humidity : 20%~60% RH
Immunity Against Electrostatic Voltage : 2 KV (HBM)
Curvature : > 60mm
Dimension : 96.5×23.2 (mm) ±0.5(mm)
Installation : Stick on the windshield ( Parking Applications )
